HF-186B-1复合夹胶机

玻璃真空热合夹胶机简介工作原理:玻璃真空热合夹胶机采用真空袋的原理,对玻璃进行抽真空,在加热的条件下,将EVA胶片融化,使玻璃及中间材料贴合在一起,从而生产出夹层,夹丝,夹膜或夹胶玻璃。夹胶机可将丝布,纸制品,字画和紫外线单向透视膜,调光膜等功能膜或特定的胶片,与普通玻璃通过真空热合,生产出多种功能的工艺夹层玻璃和装饰玻璃,也可用于玻璃与PC板,玻璃生产不需要附带,高压釜和层压机。玻璃真空热合夹胶机结构简单可靠,能耗低,质量好,占地面积少,投资少,生产成本低,适用范围广,产量高,适合工业化生产要求。

全国服务热线:19128626545

手机服务热线:18680589491

在线咨询


玻璃真空热合夹胶机简介

工作原理:

玻璃真空热合夹胶机采用真空袋的原理,对玻璃进行抽真空,在加热的条件下,将EVA胶片融化,使玻璃及中间材料贴合在一起,从而生产出夹层,夹丝,夹膜或夹胶玻璃。

夹胶机可将丝布,纸制品,字画和紫外线单向透视膜,调光膜等功能膜或特定的胶片,与普通玻璃通过真空热合,生产出多种功能的工艺夹层玻璃和装饰玻璃,也可用于玻璃与PC板,玻璃生产不需要附带,高压釜和层压机。

玻璃真空热合夹胶机结构简单可靠,能耗低,质量好,占地面积少,投资少,生产成本低,适用范围广,产量高,适合工业化生产要求。

The working principle of glass vacuum heating & laminating machine

By adopting vacuum bag principle,it can joint glass with EVA films through heating and vacuum glass to make laminated glass.

It laminates two pieces of glass into one whole art glass through heating laminated materials and glass for peptezing under vacuum conditions.This machine normal float glass with silk,cotton,paper products,drawings,PET films or special plastecal films to make various art glass and decorative glass.It can also be used to laminate glass with PC sheet,soft sheet and simple and reliable in structure,low consumpteve in energy,good in quantity.which is widely used in glass processing to meet industrialization requirements of modern enterprises.




主要技术参数

型号  Model No

HF-168B

额定电压  Rated Voltage

380V-440V

装机总功率  Installation Wattage

28KW

加热功率  Heating Wattage

22KW

风机功率  Motor Wattage

4.5KW

可做玻璃尺寸  Glass size

1.85m*3.2m

外形尺寸  Machine dimension

3.5m*2.5m*1.25m

真空床层数 Layer number of silicone beds

2层

机身重量  Weight

1850KG





 玻璃真空热合夹胶机功能、特点:

1. 烘箱以风道式运送热风,此设计能使机箱内部温度均匀的进行加热工作。箱内热量均衡、热损耗小,采用优质岩棉和硅酸铝棉材料做成的箱壁,具有良好的保温效果。

2. 真空床用优质的原生硅胶板拼合而成,经久耐用。

3. 控制箱设计合理、简捷,预设程序一步走完,操作十分简便。

4. 本机既可生产夹胶、夹丝玻璃,还可以当烤箱生产聚晶烤漆。

5. 有效空间使用,在真空床范围内可任意拼放玻璃,不受玻璃形状和厚度的限制。

6. 高效省电,2-3小时可生产一炉5层硅胶床“合片玻璃”,耗电约35-40度。

The function and characteristics of glass vacuum heating & laminating machine

1. The machine inside use circulation air to keep the temperature balance and low consumption.Its wall is make good quality stainless panel inside use special cotton to keep high temperature.

2. Vacuum beds jointed with good quality and anti-scratch silicone sheet.

3. Its electric cabinet is reasonable in designated easy way to operate by presenting in one step.

4. It can used to make laminated glass and polymer paint baked.

5. Space-saving,galss can be put on vacuum bed freely and is not subject to its shape and thickness.

6. Efficient energy saving,2-3hours to produce a 5 layer of silica gel bedglass,the power consumption is about 35-40degrees.





 操作注意事项:

1. 电机必须正传,如果反转,必须重新接线。

2. 电控箱必须由专业操作人员操作,检查电箱时,必须保证电源完全断开。

3. 炉内温度高于常温时,操作人员切勿走进箱内。

4. 硅胶条、硅胶板刮抗拉力只达到普通橡胶的1/5,故一定要小心与玻璃接触,以免划破。发现有破损,用高品质的玻璃胶补漏,温度较高时硅胶板容易破损,请勿翻动。

5. 真空泵要勤换机油,操作环境湿度较大时,机油会吸附水分,导致机油发白,真空度明显下降,甚至于水分的增加,使机油溢出来。机油在经过一段时间的静置后,水、油分层,水分弃置,上层的机油可适当使用。

6. 真空泵放置的位置要通风,已方便散热。



Operation Cautions

1. the motor turns counterclockwise,cables shall be connected again.

2. Electric cabinet shall be operated by professional technician.When it is examined,power shall be switched off completely.

3. Dont walk into the amchin when its temperature is higher than moderate temperature.

4. Anti-scratching Tate is only 20 when the silicone bag in high temperature,so please be careful not be scratched by sharp glass.If damaged easily.

5. Vacuum pump Oil shall be changed regularly.Under working environment,vacuum pump to make low pump suction capacity or oil overflow from pump,clean the vacuum pump when you didntuse the pump after two weeks.change oil, let the pump working to make sure pump is ok.

6. Vacuum pump shall be put in a dry and ventilating place for convenience of releasing heat.





玻璃真空热合夹胶机用途:

夹胶机可生产以下产品:

工程类型

产品类别

工程玻璃

幕墙夹胶玻璃、KTV装饰、夹胶夹丝、会所、酒店装饰等

强化玻璃

玻璃衣柜门、玻璃橱柜门、玻璃移门、玻璃隔断门等

家装玻璃

屏风、电视背景墙、玄关、墙面、吊顶、地板等

家具玻璃

玻璃台面、玻璃茶几、玻璃柜、鱼缸玻璃等

电器玻璃

调光玻璃、灯罩玻璃、冰箱面板、电磁屏蔽、电器面板玻璃等

影像玻璃

婚纱水晶玻璃、人像写真玻璃、相册玻璃等










                   户外夹胶玻璃雨棚                                                                                             室内夹丝背景墙                                                                                            办公室夹丝玻璃移门
